Flapper Check Valve(Swash Plate Type)
Pressure range ：CLASS 150Lb~2500Lb
Nominal diameter ：NPS 2~60″
Body material;Carbon steel, Stainless steel, duplex stainless steel, Alloy steel, Nickel alloy
4.End connection ： RF ,RTJ, Wafer ,Wafer lug
Desian standards:ASME B16.34,BS1868. API6D
Length of structure: ASME B16.10
Flange size: ASME B16.5
Inspection and testing: APl 598
Nominal diameter ：NPS 2~60″
Body material;Carbon steel, Stainless steel, duplex stainless steel, Alloy steel, Nickel alloy
4.End connection ： RF ,RTJ, Wafer ,Wafer lug
Desian standards:ASME B16.34,BS1868. API6D
Length of structure: ASME B16.10
Flange size: ASME B16.5
Inspection and testing: APl 598
Quantity
How does Flapper Check Valve work?
The flapper check valve works on the differential pressure principle. This is the position to which the valve disc opens depending on the suction pressure level. The inlet pressure needs to be high to provide enough force to force the disc fully open. The suction pressure is provided by the pump. Once the valve is open, the fluid continues to flow through the flapper check valve until the pump pressure begins to decrease. At the instant the fluid pressure decreases or the pump stops, the disc returns to the seat position, ensuring there is no reverse fluid flow. Fluid backflow can damage plumbing equipment such as pumps or boilers, and can also contaminate liquids such as water and beverages.
Design Features & Benefits
Because they were designed with one specific purpose in mind – preventing water hammer – SJ’s silent check valves are known worldwide for their effectiveness in preventing reverse flow and water hammer-related problems. Moreover, our silent check valves are designed to start opening at approximately 0.5 PSI differential pressure, with full opening occurring at 1.0 PSI differential pressure.
In addition, S J’s Flapper Check Valve feature the following characteristics:
- Fully meet MSS SP 126-2000 Steel In-Line Spring-Assisted Center Guided Check Valves Standards
- Available with soft seats for bubble-tight shutoff
- Can be used in liquid, gas, or steam applications
- Allows smoother fluid flow, and responsive opening and closing without the sudden movements that cause water hammer
